Mantid Workbench Changes

New Features

  • The crosshair button is now enabled in tiled plots(subplots).

  • The crosshair has now been optimized using matplotlib’s blitting function for fast rendering. It can very closely tracks mouse movement with minimal lag now.

  • The ability to scale axis and colorbars to symlog has been added to plots. An option to specify the extent of the linear portion of the symlog axis (linthresh) has been added to the axes tab widget in the plot config dialog.

MantidWorkbench now features a new, integrated HTML-based help viewer, replacing the previous Qt Assistant-based system. This modernization provides a more streamlined user experience and aligns with current web standards.

Key Enhancements & Foundational Changes:

  • Modern Help Viewer: A new help window directly renders HTML documentation within MantidWorkbench, offering improved navigation and display.

  • Standardized Documentation Path: To support the new viewer, HTML documentation now installs to a consistent location: <prefix>/share/doc/html/. * Build systems (CMake, conda recipes) have been updated for this standard.

  • Reliable Document Discovery: * The new help viewer uses an absolute path (docs.html.root in Mantid.properties) to reliably locate local documentation. * Legacy internal components (C++ MantidHelpWindow and Python gui_helper.py fallbacks, during their transition phase) have also been updated to recognize the new share/doc/html/ directory.

  • Phasing out Qt Assistant: * Conda build scripts for mantiddocs and related packages now disable the generation of QtHelp/QtAssistant components (e.g., .qhc files), as part of the move away from Qt Assistant.

  • CMake Configuration Streamlined: * Related cleanup of some unused CMake variables in Framework/Kernel/CMakeLists.txt was performed.

Impact:

  • Delivers a more modern and integrated help experience within MantidWorkbench.

  • Ensures consistent and reliable access to locally installed documentation.

  • Progresses Mantid’s codebase by removing dependencies on the older Qt Assistant technology.

Bugfixes

InstrumentViewer

New features

Bugfixes

SliceViewer

New features

Bugfixes

Release 6.14.0
